DELL INSPIRON 1464 NOT CHARGING THE BATTERY

Post by prakash pal »

Dell inspiron 1464
Problem... Not charging the battery
On a BIOS it's showing none
I checked PSID Signal 3v ok
On a SIO PS-ID 3V OK
All related resister capacitor Diode n via components r Ok
But shome time charging mosfet is showing shot with ground
Then trace the track charging IC showing shot pin no 20&21 LDO dlo short I checked all related components Ok finally I replace the charging ic problem solve........
Attachments
Top
User avatar
javed
TOP poster
TOP poster
Posts: 91
Joined: Mon Dec 14, 2015 10:51 am

Re: DELL INSPIRON 1464 NOT CHARGING THE BATTERY

Post by javed »

nice post
Top
User avatar
dnalaptopmalang
Newbie
Newbie
Posts: 4
Joined: Mon Oct 10, 2016 4:12 pm

Re: DELL INSPIRON 1464 NOT CHARGING THE BATTERY

Post by dnalaptopmalang »

i like this

[ Post made via Android ] Image
Top
esmat-fadak
Guru
Guru
Posts: 182
Joined: Thu Feb 18, 2016 11:32 am
Location: Kabul, Afghanistan

Re: DELL INSPIRON 1464 NOT CHARGING THE BATTERY

Post by esmat-fadak »

Good job

[ Post made via Android ] Image
