Lenovo Ideacentre B320 AIO Power on But no Display
-
ankur05djn
- Newbie
- Posts: 0
- Joined: Wed Jul 27, 2016 10:54 am
Lenovo Ideacentre B320 AIO Power on But no Display
When press power button PC system is power on power led blink with LCD flickering but if you press the TV button system power on with display.After tracing the main board found +5vDual abnormal then found
pc321 pf is short replaced the pf.Now PC system is power on with lenovo logo faulty pf picture is attached.....
pc321 pf is short replaced the pf.Now PC system is power on with lenovo logo faulty pf picture is attached.....
- Attachments
-
Last edited by ankur05djn on Thu Dec 01, 2016 9:04 am, edited 1 time in total.
-
suryajaved
- IndiaReFix team
- Posts: 631
- Joined: Mon Nov 30, 2015 8:37 am
- Location: CHANDRAPUR
Re: Lenovo Ideacentre B320 AIO Power on But no Display
where is picture dear ?
-
nanooshazi
- TOP poster
- Posts: 54
- Joined: Wed Apr 12, 2017 11:35 pm
Re: Lenovo Ideacentre B320 AIO Power on But no Display
try this bios
- Attachments
-
- DXKT33A.zip
- (1.42 MiB) Downloaded 240 times
